CENTRIC 123.65012 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.65012 Specifications
Product Attributes
| Weight [cntrc] Kgs | 15.000 |
| Weight [cntrc] Lbs | 33.000 |
| Mounting Type [cntrc] | Behind the Hub |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 137.414 |
| Hub Hole / Register [cntrc] In | 5.410 |
| Height [cntrc] Mm | 128.016 |
| Height [cntrc] In | 5.040 |
| Friction Surface Width [cntrc] Mm | 88.900 |
| Friction Surface Width [cntrc] In | 3.500 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 307.100 MM |
| Maximum Brake Diameter (Discard) | 12.090 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 356.108 MM |
| Outside Diameter | 14.020 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.510 MM |
| Mounting Hole Diameter | 0.650 IN |
| Nominal Drum Diameter | 304.800 MM |
| Nominal Drum Diameter | 12.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890052722 |
CENTRIC 123.65012 Cross References
| Brand | Part Number |
|---|---|
| 101665, 1665, 52-60465, 5260465, BD60465 | |
| N/A | 52-60465, 5260465, BD60465, E127-70-017, E128-70-017, 8861, BD8861, 123.65012, 63 92 750, 8861C, 8861CG, D4UZ1113A, D4UZ1114A, D8TZ1113C, D8TZ1114B, E4TZ1113B, E4TZ1114A, E8TZ1126A, 140344, PDR0344, 202610, 440-1250, 6401250, 848, AD8512, AD8512E, D5665, E8359, E12770017, E12870017, 87073, 23049, X21581, BD1022, 101665, 1665, 1665R, 1665DGS, 78842012, 78-42012, 7842012, 8842012, 68255, 177320, 36554054 |
| PRONTO | BD8861 |
| RAYBESTOS | 1665, 1665R |
CENTRIC 123.65012 Fits Vehicles
- Ford F-350 (1973-1989)
- Ford F-250 (1980-1989)
- Ford E-350 Econoline Club Wagon (1977-1986)
- Ford E-350 Econoline (1975-1986)
- Ford E-250 Econoline Club Wagon (1984-1986)
- Ford E-250 Econoline (1984-1986)
