Centric 123.65008 - C-Tek Standard Brake Drum
$8449
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 8.636 |
| Weight [cntrc] Lbs | 19.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 72.898 |
| Hub Hole / Register [cntrc] In | 2.870 |
| Height [cntrc] Mm | 92.202 |
| Height [cntrc] In | 3.630 |
| Friction Surface Width [cntrc] Mm | 70.104 |
| Friction Surface Width [cntrc] In | 2.760 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 282.400 MM |
| Maximum Brake Diameter (Discard) | 11.120 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 324.104 MM |
| Outside Diameter | 12.760 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.494 MM |
| Mounting Hole Diameter | 0.610 IN |
| Nominal Drum Diameter | 280.200 MM |
| Nominal Drum Diameter | 11.030 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890052692 |
Part Interchanges
CENTRIC 123.65008 Cross Reference
We have 4 alternatives for the 123.65008 by CENTRIC:
Fits Vehicles
- Ford E-200 Econoline (1969-1974)
- Ford E-100 Econoline Club Wagon (1975-1976)
- Ford F-150 (1975-1976)
- Ford F-100 (1968-1976)
- Ford E-150 Econoline (1975-1976)
- Ford E-100 Econoline (1973-1976)
- Ford E-150 Econoline Club Wagon (1975-1976)
