CENTRIC 123.63041 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.63041 Specifications
Product Attributes
| Weight [cntrc] Kgs | 4.545 |
| Weight [cntrc] Lbs | 10.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 73.660 |
| Hub Hole / Register [cntrc] In | 2.900 |
| Height [cntrc] Mm | 67.818 |
| Height [cntrc] In | 2.670 |
| Friction Surface Width [cntrc] Mm | 55.118 |
| Friction Surface Width [cntrc] In | 2.170 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 221.200 MM |
| Maximum Brake Diameter (Discard) | 8.709 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 250.698 MM |
| Outside Diameter | 9.870 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 13.970 MM |
| Mounting Hole Diameter | 0.550 IN |
| Nominal Drum Diameter | 219.964 MM |
| Nominal Drum Diameter | 8.660 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890140689 |
CENTRIC 123.63041 Cross References
| Brand | Part Number |
|---|---|
| 109541, 52-125300, 52125300 | |
| MAGMA PRODUCTS | PMU14081 |
| N/A | BD125300, 52-125300, 52125300, E128-68-046, 80005, BD80005, 119541, 80005G, 4601798, 4616236, 140634, PDR0634, 203052, 440-1497, 6401497, 1057, AD8341, AD8341E, D9416, E12868046, 100764, 87541, YH140634, X21755, 23094, BD1606, 109541, 9541, 9541R, 9541DGS, 8832041, 78832041, 36540019 |
| PRONTO | BD80005 |
| RAYBESTOS | 9541, 9541R |
| WAGNER | BD125300 |
CENTRIC 123.63041 Fits Vehicles
- Eagle Vision (1997)
- Chrysler Intrepid (1993-1996)
- Dodge Intrepid (1993-1994, 1997)
- Chrysler Concorde (1997)
