CENTRIC 123.63014 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.63014 Specifications
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Kgs | 7.045 |
| Weight [cntrc] Lbs | 15.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 72.136 |
| Hub Hole / Register [cntrc] In | 2.840 |
| Height [cntrc] Mm | 104.902 |
| Height [cntrc] In | 4.130 |
| Friction Surface Width [cntrc] Mm | 56.388 |
| Friction Surface Width [cntrc] In | 2.220 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 255.500 MM |
| Maximum Brake Diameter (Discard) | 10.060 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 318.008 MM |
| Outside Diameter | 12.520 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 15.494 MM |
| Mounting Hole Diameter | 0.610 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052524 |
CENTRIC 123.63014 Cross References
| Brand | Part Number |
|---|---|
| 122.63014, F1EZ19980KK | |
| N/A | 52-60321, 5260321, BD60321, E128-68-019, E127-68-019, 8838, BD8838, 63 91 760, D91 760, 8838G, 112513, 692, J3219577, J3219579, J3231668, J8124255, J8124256, J8129462, J8130299, 8952001151, 100581, 8124255, 8124256, 8129462, 8130299, J3219575, 3219575, 3219577, 3219579, 3231668, 52001151, 3231640, 140303, PDR0303, 204380, 4401105, 6401105, 440-1105, 770, AD8314, AD8314E, D2513, E12768019, 87210, 212253C, YH140303, 23021, X21527, BD1087, 2513, 2513DGS, 2513R, 102513, 78832014, 8832014, 7832014, 78-32014, 68065, 177221, 36542002 |
| PRONTO | BD8838 |
| RAYBESTOS | 2513, 2513R |
| WAGNER | BD60321 |
CENTRIC 123.63014 Fits Vehicles
- American Motors Ambassador (1971-1974)
- American Motors Matador (1971-1973, 1975-1976)
- American Motors Hornet (1973-1977)
- American Motors Spirit (1979)
- American Motors Pacer (1976-1980)
- American Motors Gremlin (1977-1978)
- American Motors Concord (1978-1979)
- American Motors AMX (1978-1980)
- Jeep Wrangler (1987-1989)
- Jeep Wagoneer (1984-1989)
- Jeep Comanche (1986-1989)
- Jeep Cherokee (1984-1989)
