CENTRIC 123.62014 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.62014 Specifications
Product Attributes
| Weight [cntrc] Kgs | 7.273 |
| Weight [cntrc] Lbs | 16.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 120.650 |
| Bolt Circle Diameter [cntrc] In | 4.750 |
| Hub Hole / Register [cntrc] Mm | 70.612 |
| Hub Hole / Register [cntrc] In | 2.780 |
| Height [cntrc] Mm | 75.438 |
| Height [cntrc] In | 2.970 |
| Friction Surface Width [cntrc] Mm | 62.738 |
| Friction Surface Width [cntrc] In | 2.470 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 243.600 MM |
| Maximum Brake Diameter (Discard) | 9.590 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 299.974 MM |
| Outside Diameter | 11.810 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 13.210 MM |
| Mounting Hole Diameter | 0.520 IN |
| Nominal Drum Diameter | 241.300 MM |
| Nominal Drum Diameter | 9.500 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052371 |
CENTRIC 123.62014 Cross References
| Brand | Part Number |
|---|---|
| 2027, 2091, 2091DGS, 52-60736, 5260736, BD60165, BD60736 | |
| MAGMA PRODUCTS | PMU22017 |
| N/A | 52-60736, BD60165, BD60736, 5260736, E128-67-019, 8818, 8839, BD8839, D93 520, 112091, 8818G, 8839G, 1236997, 1240212, 1249146, 1249149, 1255496, 1256741, 1359634, 18006034, 25506137, 9788681, 382307, 383229, 383829, 202181, 201391, 140039, 140454, PDR0039, PDR0454, 6401136, 6401359, 440-1359, 4401359, 805, 855, AD8214E, D2091, D2027, E12867019, 87225, 87007, 23052, X21459, X21534, BD1262, 102091, 2091, 2091DGS, 2091R, 2027, 2027R, 2027DGS, ZAD8214E, 78836014, 78-36014, 7836014, 68015, 68040, 177242, 177299, 36547014 |
| PRONTO | BD8839 |
| RAYBESTOS | 2027, 2027R, 2091, 2091R |
| WAGNER | BD60736 |
CENTRIC 123.62014 Fits Vehicles
- Buick Sportwagon (1970-1972)
- Buick Special (1964-1969)
- Pontiac Tempest (1964-1970)
- Pontiac Grand Safari (1977-1978)
- Pontiac GTO (1964-1973)
- Oldsmobile Jetstar 88 (1964-1966)
- Oldsmobile F85 (1964-1972)
- Oldsmobile 442 (1964-1971)
- Buick GS 455 (1970-1972)
- Buick GS 400 (1968-1969)
- Chevrolet Chevelle (1973)
- Buick GS 350 (1968-1969)
- Buick Gran Sport (1965-1967)
- Buick GS (1970-1972)
- Pontiac Phoenix (1977-1979)
- Oldsmobile Bravada (1991)
- Pontiac Parisienne (1983-1986)
- Pontiac Grand Am (1973-1975, 1978-1980)
- Pontiac Catalina (1977-1981)
- Pontiac Ventura (1975-1977)
- Pontiac LeMans (1964-1975, 1978-1981)
- GMC Sonoma (1991)
- Pontiac Grand Prix (1969-1975, 1978-1987)
- Pontiac Grand LeMans (1975, 1978-1983)
- Pontiac Firebird (1967-1969, 1974-1992)
- Pontiac Bonneville (1977-1986)
- Oldsmobile Toronado (1979-1983)
- Oldsmobile Omega (1975-1979)
- Oldsmobile Delta 88 (1977-1985)
- GMC Sprint (1971-1975)
- Oldsmobile Cutlass Supreme (1967-1975, 1978-1988)
- Oldsmobile Cutlass (1964-1975, 1978-1981, 1985-1987)
- Oldsmobile Cutlass Cruiser (1980-1983)
- Oldsmobile Cutlass Calais (1978-1984)
- Oldsmobile Cutlass Salon (1975, 1978-1980, 1985-1987)
- Oldsmobile 98 (1978-1979)
- GMC S15 (1982-1990)
- GMC S15 Jimmy (1983-1991)
- GMC Caballero (1978-1987)
- Chevrolet S10 (1982-1991)
- Chevrolet S10 Blazer (1983-1991)
- Chevrolet Nova (1975-1979)
- Chevrolet Monte Carlo (1970-1975, 1978-1988)
- Chevrolet Malibu (1973-1975, 1978-1983)
- Chevrolet Laguna (1973-1975)
- Chevrolet LLV (1987-1988)
- Chevrolet Impala (1977-1985)
- Chevrolet El Camino (1970-1975, 1978-1987)
- Chevrolet Caprice (1977-1990)
- Chevrolet Camaro (1975-1992)
- Buick Apollo (1975)
- Buick Skylark (1964-1972, 1976-1979)
- Buick Riviera (1979-1985)
- Buick Regal (1973-1975, 1978-1987)
- Buick LeSabre (1977-1986)
- Buick Estate Wagon (1977-1983)
- Buick Electra (1977-1985)
- Buick Century (1973-1975, 1978-1981)
