CENTRIC 123.61006 - Standard Brake Drum
$4349
MSRP: $47.98
Save: $4.49
In stock
limited availability at this price!
. Learn more
CENTRIC part description
California Proposition 65 Warning
California Proposition 65 Warning
| Make | Ford, Mercury |
| Model | Comet, Falcon, Maverick, Mustang |
| Year | 1966 |
Product Description
C-Tek Standard Brake Drum
Application Summary
Ford Falcon 1969-1966, Maverick 1973-1970, Mustang 1970-1967, Mercury Comet 1972-1971
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
C-Tek; Centric; Standard brake rotor; standard brake drum; Centric standard Drums; Centric c-tek standard brake drum
Product Attributes
| Maximum Brake Diameter (Discard) | 230.900 MM |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 273.050 MM |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.494 MM |
| Nominal Drum Diameter | 228.600 MM |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Friction Surface Width [cntrc] In | 2.520 |
| Friction Surface Width [cntrc] Mm | 64.008 |
| Height [cntrc] In | 3.130 |
| Height [cntrc] Mm | 79.502 |
| Hub Hole / Register [cntrc] In | 2.430 |
| Hub Hole / Register [cntrc] Mm | 61.722 |
| Mounting Type [cntrc] | Floating |
| Weight [cntrc] Kgs | 5.977 |
| Weight [cntrc] Lbs | 13.150 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890052173 |
CENTRIC 123.61006 Cross Reference
We have 3 alternatives for the 123.61006 by CENTRIC:
Fits Vehicles
- Mercury Comet (1971-1972)
- Ford Mustang (1967-1970)
- Ford Maverick (1970-1973)
- Ford Falcon (1966-1969)
