(888) 312-8812 Login SignupCENTRIC 123.48001 C-Tek Standard Brake Drum
Tap to view 4 more
$35.69
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 123.48001 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.48001 Specifications
Product Attributes
| Weight [cntrc] Kgs | 3.864 |
| Weight [cntrc] Lbs | 8.500 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 55.100 |
| Hub Hole / Register [cntrc] In | 2.169 |
| Height [cntrc] Mm | 65.500 |
| Height [cntrc] In | 2.579 |
| Friction Surface Width [cntrc] Mm | 36.000 |
| Friction Surface Width [cntrc] In | 1.417 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 182.000 MM |
| Maximum Brake Diameter (Discard) | 7.165 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 221.500 MM |
| Outside Diameter | 8.720 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 9.800 MM |
| Mounting Hole Diameter | 0.386 IN |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890052074 |
CENTRIC 123.48001 Cross References
| Brand | Part Number |
|---|---|
| 122.48001, F1EZ15K866H | |
| MAGMA PRODUCTS | PMU22065 |
| N/A | BD61935, 0802340, 0832340, 3572, BD3572, 63 93 010, 6393010, 4351160B00, 3572G, 100858, 96060541, 140573, PDR0573, 201398, 6401637, JBD191, JBD191E, D9402, 87473, X30740, 21095, BD1579, 1473, 1473DGS, 1473R, 78-10006, 7810006, 8810006, 78810006, 36550001, 177398 |
| PRONTO | BD3572 |
| RAYBESTOS | 1473, 1473R |
| WAGNER | BD61935 |
CENTRIC 123.48001 Fits Vehicles
- Geo Metro (1989-1994)
