CENTRIC 122.62037 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.62037 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 3.841 |
| Weight [cntrc] Lbs | 8.450 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 57.000 |
| Hub Hole / Register [cntrc] In | 2.244 |
| Height [cntrc] Mm | 56.998 |
| Height [cntrc] In | 2.244 |
| Friction Surface Width [cntrc] Mm | 38.800 |
| Friction Surface Width [cntrc] In | 1.528 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 201.000 MM |
| Maximum Brake Diameter (Discard) | 7.913 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 230.100 MM |
| Outside Diameter | 9.059 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.600 MM |
| Mounting Hole Diameter | 0.496 IN |
| Nominal Drum Diameter | 200.000 MM |
| Nominal Drum Diameter | 7.874 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890305767 |
CENTRIC 122.62037 Cross References
| Brand | Part Number |
|---|---|
| BD126557, 829352670095 | |
| N/A | BD126557, BD920110, 920110, YH200409, 21104, 1408-233908, 80124, 80115G, 21106, 96471783, 96471784, 96473233, 96473234, 95903585, 96470999, 96471276, 96471277, 96471771, PDR0829, 860008, 1770454, 36547026 |
| RAYBESTOS | 9781R |
| Raybestos Brakes | 9781R |
| WAGNER | BD126557, BD126557E |
CENTRIC 122.62037 Fits Vehicles
- Chevrolet Beat (2018-2020)
- Chevrolet Spark (2011-2015)
- Pontiac G3 Wave (2009)
- Pontiac Wave5 (2005, 2007)
- Pontiac G3 (2009-2010)
- Chevrolet Aveo5 (2006-2011)
- Pontiac Wave (2005-2008)
- Chevrolet Aveo (2004-2018)
