CENTRIC 122.62008 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.62008 Specifications
Product Attributes
| Weight [cntrc] Kgs | 8.636 |
| Weight [cntrc] Lbs | 19.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 120.650 |
| Bolt Circle Diameter [cntrc] In | 4.750 |
| Hub Hole / Register [cntrc] Mm | 71.374 |
| Hub Hole / Register [cntrc] In | 2.810 |
| Height [cntrc] Mm | 89.408 |
| Height [cntrc] In | 3.520 |
| Friction Surface Width [cntrc] Mm | 61.214 |
| Friction Surface Width [cntrc] In | 2.410 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 243.600 MM |
| Maximum Brake Diameter (Discard) | 9.590 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 294.894 MM |
| Outside Diameter | 11.610 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 11.430 MM |
| Mounting Hole Diameter | 0.450 IN |
| Nominal Drum Diameter | 241.000 MM |
| Nominal Drum Diameter | 9.488 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890045144 |
CENTRIC 122.62008 Cross References
| Brand | Part Number |
|---|---|
| 2045, 2045DGS, 102045, 52-60094, 5260094, BD60094 | |
| N/A | BD60094, E127-67-013, 63 93 510, 6393510, 8798, 8798G, 112056, 3841176, 3841188, 3853712, 3853912, 3987445, 3996135, 3996145, 9787445, 9987445, PDR0053, 140053, 6401006, 842, AD8208, D2045, E12767013, 87004, YH140053, X21391, 23064, BD1046, 8836008, 177230, 18B466, 36547010 |
| RAYBESTOS | 2045, 2045R, 2091R, 2091 |
| Raybestos Brakes | 2045, 2045R |
| WAGNER | BD60094 |
CENTRIC 122.62008 Fits Vehicles
- GMC G1500 (1964-1966)
- Pontiac Ventura (1971-1974)
- Pontiac Firebird (1970-1973)
- Oldsmobile Omega (1973-1974)
- GMC Sprint (1971-1972)
- GMC G15/G1500 Van (1967-1971)
- GMC G1000 Series (1964-1966)
- Chevrolet Nova (1969-1974)
- Chevrolet Monte Carlo (1970-1972)
- Chevrolet Malibu (1965-1966)
- Chevrolet G10 Van (1964-1971)
- Chevrolet El Camino (1964-1972)
- Chevrolet Corvair (1965-1969)
- Chevrolet Chevy II (1964-1968)
- Chevrolet Chevelle (1964-1972)
- Chevrolet Camaro (1967-1974)
- Buick Apollo (1973-1974)
- Buick Skylark (1975)
