CENTRIC 122.61026 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
CENTRIC 122.61026 Specifications
Product Attributes
| Weight [cntrc] Kgs | 3.409 |
| Weight [cntrc] Lbs | 7.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 107.950 |
| Bolt Circle Diameter [cntrc] In | 4.250 |
| Hub Hole / Register [cntrc] Mm | 63.500 |
| Hub Hole / Register [cntrc] In | 2.500 |
| Height [cntrc] Mm | 63.500 |
| Height [cntrc] In | 2.500 |
| Friction Surface Width [cntrc] Mm | 41.910 |
| Friction Surface Width [cntrc] In | 1.650 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 204.700 MM |
| Maximum Brake Diameter (Discard) | 8.060 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 237.490 MM |
| Outside Diameter | 9.350 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.224 MM |
| Mounting Hole Diameter | 0.560 IN |
| Nominal Drum Diameter | 203.200 MM |
| Nominal Drum Diameter | 8.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | US |
| UPC | 805890037743 |
CENTRIC 122.61026 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 2690, 2690R |
| N/A | BD60728, 8933, 8933G, E3EZ1113D, E8AZ1126B, E3FZ1113D, E4FZ1113A, 202331, PDR0429, 140429, 4401450, 6401450, 754, AD8126, D2690, 87285, X21664, BD1458, 2690DGS, 8834026, 177326, 36554023 |
CENTRIC 122.61026 Fits Vehicles
- Mercury Lynx (1982-1985)
- Mercury LN7 (1983)
- Ford Escort (1982-1985)
- Ford EXP (1983-1985)
CENTRIC 122.61026 Cross References
We have 4 alternatives for the 122.61026 by CENTRIC:
