Centric 122.44034 - Premium Brake Drum
$2199
MSRP: $38.81
Save: $16.82
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Attributes
| Weight [cntrc] Kgs | 4.318 |
| Weight [cntrc] Lbs | 9.500 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Stud Thread Pitch [cntrc] Mm | 1.50 |
| Hub Hole / Register [cntrc] Mm | 54.000 |
| Hub Hole / Register [cntrc] In | 2.126 |
| Height [cntrc] Mm | 80.500 |
| Height [cntrc] In | 3.169 |
| Friction Surface Width [cntrc] Mm | 34.400 |
| Friction Surface Width [cntrc] In | 1.354 |
| Product Grade [cntrc] | Premium |
| 132 | 12 MM |
| Maximum Brake Diameter (Discard) | 181.000 MM |
| Maximum Brake Diameter (Discard) | 7.126 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 207.000 MM |
| Outside Diameter | 8.150 IN |
| Outer Cooling Fins | No |
| Nominal Drum Diameter | 179.700 MM |
| Nominal Drum Diameter | 7.075 IN |
CENTRIC 122.44034 Cross Reference
We have 7 alternatives for the 122.44034 by CENTRIC:
