CENTRIC 121.66027 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.66027 Specifications
Product Attributes
| Inner Bearing # [cntrc] | 410.91035 |
| Product Grade [cntrc] | Standard |
| Outer Bearing # [cntrc] | 415.66000 |
| Inner Seal # [cntrc] | 417.66000 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Lbs | 37.000 |
| Misc Holes [cntrc] | 0 |
| Outer Race # [cntrc] | 416.66000 |
| Weight [cntrc] Kgs | 16.820 |
| Discard Thickness | 30.860 MM |
| Discard Thickness | 1.215 IN |
| Nominal Thickness | 32.700 MM |
| Nominal Thickness | 1.287 IN |
| Stud Thread Diameter | 14.000 MM |
| Overall Height | 126.100 MM |
| Overall Height | 4.965 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 317.200 MM |
| Rotor Outside Diameter | 12.488 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.500 MM |
| Bearings Included | No |
| Center Hole Diameter | 116.600 MM |
| Center Hole Diameter | 4.591 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890051060 |
CENTRIC 121.66027 Cross References
| Brand | Part Number |
|---|---|
| 56263RGS, 56263, 1056263, 52-125212, 52125212, BD125212 | |
| MAGMA PRODUCTS | PMR225197 |
| N/A | BD125212, 52-125212, 52125212, E126-71-032, 5598, BR5598, R93 480, 107251, 5598G, 15649969, 15659250, 15712781, 15721421, 15981318, 15981319, 141818, PRT1818, 101980, 101980E, 86263, 311, AR8627E, D17598, E12671032, 27081, X50657, BR1906, 1056263, 56263, 56263R, 56263RGS, ZAR8627, 19775, 7844027, 78-44027, 78944027, 65690, 18A507, 177813, 60048023 |
| RAYBESTOS | 56263, 56263FZN, 56263R |
| WAGNER | BD125212, BD125212E |
CENTRIC 121.66027 Fits Vehicles
- Chevrolet G30 (1996)
- Chevrolet Express 3500 (1996-2001)
- Chevrolet Express 2500 (1996-2002)
- Chevrolet C3500 (1995-2000)
- Chevrolet C2500 Suburban (1992-1999)
- Chevrolet C2500 (1995-2000)
- Chevrolet C1500 Suburban (1994-1999)
- GMC Savana 3500 (1996-2001)
- GMC G3500 (1996)
- GMC C3500HD (1995-1996)
- GMC Savana 2500 (1996-2002)
- GMC C3500 (1995-2000)
- GMC C2500 Suburban (1992-1999)
- GMC C2500 (1996-2000)
- GMC C1500 Suburban (1994-1999)
