(888) 312-8812 Login SignupCENTRIC 121.66024 C-Tek Standard Brake Rotor
Tap to view 4 more
$12799
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Jul 9
CENTRIC 121.66024 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.66024 Specifications
Product Attributes
| Product Grade [cntrc] | Standard |
| Inner Bearing # [cntrc] | 410.91035 |
| Outer Race # [cntrc] | 416.66000 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Kgs | 17.730 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 39.000 |
| Inner Seal # [cntrc] | 417.66008 |
| Vane Style [cntrc] | Straight |
| Outer Bearing # [cntrc] | 415.66000 |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 30.860 MM |
| Discard Thickness | 1.215 IN |
| Nominal Thickness | 32.700 MM |
| Nominal Thickness | 1.287 IN |
| Stud Thread Diameter | 0.563 IN |
| Overall Height | 120.700 MM |
| Overall Height | 4.752 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 317.500 MM |
| Rotor Outside Diameter | 12.500 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 18.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 118.500 MM |
| Center Hole Diameter | 4.665 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890051039 |
CENTRIC 121.66024 Cross References
| Brand | Part Number |
|---|---|
| 56331, 1056331, 52-125331, 52125331, BD125331 | |
| N/A | 52-125331, 52125331, BD125331, E125-71-029, E126-71-029, 55020, BR55020, R93 080, 64 93 080, 55020G, 107268, 15674407, 141861, PRT1861, 102577, 86331, 4886331, 611, AR8624, AR8624E, D17621, E12571029, E12671029, E9813, 15641577, X51022, 27217, BR1915, 56331, 56331R, 1056331, 1056331R, 8944024, 78-44024, 7844024, 78944024, 60048021 |
| RAYBESTOS | 56331, 56331R |
| WAGNER | BD125331 |
CENTRIC 121.66024 Fits Vehicles
- Chevrolet G30 (1993-1995)
- GMC G3500 (1993-1995)
