CENTRIC 121.66004 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.66004 Specifications
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 12.950 |
| Weight [cntrc] Lbs | 28.500 |
| Product Grade [cntrc] | Standard |
| Mounting Bolt Hole Diameter | 0.587 IN |
| Mounting Bolt Hole Diameter | 14.900 MM |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Center Hole Diameter | 127.200 MM |
| Center Hole Diameter | 5.008 IN |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Mounting Bolt Hole Quantity | 8 |
| Outside Diameter | 12.870 IN |
| Outside Diameter | 326.900 MM |
| Overall Height | 3.079 IN |
| Overall Height | 78.200 MM |
| Nominal Thickness | 1.535 IN |
| Nominal Thickness | 38.990 MM |
| Discard Thickness | 37.210 MM |
| Discard Thickness | 1.465 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890140092 |
CENTRIC 121.66004 Cross References
| Brand | Part Number |
|---|---|
| 5046, 52-60597, 5260597, BD60597 | |
| MAGMA PRODUCTS | PMR225167 |
| N/A | 52-60597, BD60597, 5260597, E126-71-009, E125-71-009, 5564, BR5564, 6493430, 5564G, 12361507, 12361508, 12385855, 12385856, 4506132, 15622381, 15635678, 15649274, 15983003, 14039119, 462825, 475986, 141468, PRT1468, 101640, 85822, 4885822, 624, AR8604, AR8604E, D17301, E12571009, E12671009, E8407, E8445, 5564GT, 100353, 100353G, 210299, 210299C, 27275, X50360, BR1375, 5046, 5046R, 8944004, 78944004, 60048003, 177704 |
| PRONTO | BR5564 |
| RAYBESTOS | 5046R |
| WAGNER | BD60597 |
CENTRIC 121.66004 Fits Vehicles
- Chevrolet K3500 (1990-2000)
- Chevrolet K30 (1977-1986)
- Dodge W350 (1990-1993)
- GMC V3500 (1987-1991)
- GMC K3500 (1979-1986, 1990-2000)
- GMC K35 (1977-1978)
- Chevrolet V3500 (1989-1991)
- Chevrolet V30 (1987-1988)
