(888) 312-8812 Login SignupCENTRIC 121.66003 C-Tek Standard Brake Rotor
Tap to view 4 more
$79.98
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.66003 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.66003 Specifications
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 12.950 |
| Weight [cntrc] Lbs | 28.500 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 1.465 IN |
| Discard Thickness | 37.210 MM |
| Nominal Thickness | 38.990 MM |
| Nominal Thickness | 1.535 IN |
| Overall Height | 78.200 MM |
| Overall Height | 3.079 IN |
| Outside Diameter | 326.900 MM |
| Outside Diameter | 12.870 IN |
| Mounting Bolt Hole Quantity | 8 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 127.200 MM |
| Center Hole Diameter | 5.008 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Diameter | 17.700 MM |
| Mounting Bolt Hole Diameter | 0.697 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890050872 |
CENTRIC 121.66003 Cross References
| Brand | Part Number |
|---|---|
| 5048, 105048, 52-60622, 5260622, BD60622 | |
| MAGMA PRODUCTS | PMR225166 |
| N/A | 52-60622, 5260622, BD60622, E126-71-008, 5563, BR5563, 6493460, 5563G, 04506131, 101541, 475985, 15635530, 15649273, 4506131, 14039118, 14079008, 15365530, 145091, 141469, PRT1469, 101630, 4885843, 85843, 623, AR8603, AR8603E, D5048, E12671008, 100353, 100353G, 27371, X50348, BR1452, 5048, 5048R, 105048, 105048R, 78944003, 8944003, 78-44003, 7844003, 65745, 60040051, 177703 |
| PRONTO | BR5563 |
| RAYBESTOS | 5048R |
| WAGNER | BD60622 |
CENTRIC 121.66003 Fits Vehicles
- Chevrolet K30 (1977-1986)
- Dodge W350 (1990-1993)
- Dodge W250 (1990-1993)
- GMC V3500 (1987-1991)
- GMC K3500 (1979-1986)
- GMC K35 (1977-1978)
- Chevrolet V3500 (1989-1991)
- Chevrolet V30 (1987-1988)
