(888) 312-8812 Login SignupCENTRIC 121.65045 C-Tek Standard Brake Rotor
Tap to view 4 more
$12499
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Jul 29
CENTRIC 121.65045 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.65045 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Seal # [cntrc] | 417.65003 |
| Inner Bearing # [cntrc] | 415.68004 |
| Misc Holes [cntrc] | 0 |
| Vane Style [cntrc] | Straight |
| Outer Race # [cntrc] | 416.68001 |
| Product Grade [cntrc] | Standard |
| Weight [cntrc] Lbs | 36.500 |
| Outer Bearing # [cntrc] | 415.68002 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Inner Race # [cntrc] | 416.68003 |
| Weight [cntrc] Kgs | 16.590 |
| Discard Thickness | 28.000 MM |
| Discard Thickness | 1.102 IN |
| Nominal Thickness | 30.000 MM |
| Nominal Thickness | 1.181 IN |
| Stud Thread Diameter | 0.563 IN |
| Overall Height | 143.400 MM |
| Overall Height | 5.646 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 331.000 MM |
| Rotor Outside Diameter | 13.031 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 18.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 123.500 MM |
| Center Hole Diameter | 4.862 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890050650 |
CENTRIC 121.65045 Cross References
| Brand | Part Number |
|---|---|
| 1066527, 66527, 66527RGS, 52-125468, 52125468, BD125468 | |
| MAGMA PRODUCTS | PMR207281 |
| N/A | 52-125468, 52125468, BD125468, E126-70-050, 54021, BR54021, R92 350, BD4021KT, 54021G, 107158, F8UA1102BA, F8UZ1102BA, F5TA1102EA, F5UZ1102E, 145049, PRT5049, 102403, 102403E, 86527, 1320, AR8545E, D17778, E12670050, X50999, BR1999, 1066527, 66527, 66527R, 66527RGS, 19768, 7842045, 78-42045, 78942045, 65600, 60054135 |
| RAYBESTOS | 66527, 66527R |
| WAGNER | BD125468E, BD125468 |
CENTRIC 121.65045 Fits Vehicles
- Ford F-250 HD (1997)
- Ford F-150 Heritage (2004)
- Ford F-350 (1995-1997)
- Ford F-250 (1995-1999)
- Ford F-150 (2000-2003)
- Ford E-350 Econoline Club Wagon (1995-1998)
- Ford E-350 Econoline (1995-1998)
- Ford E-250 Econoline (1995-1999)
