Centric 121.65033 - C-Tek Standard Brake Rotor
$6549
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Disc Mounting [cntrc] | Hub & Rotor |
| Product Grade [cntrc] | Standard |
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 410.91006 |
| Weight [cntrc] Kgs | 8.180 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 18.000 |
| Outer Bearing # [cntrc] | 410.91002 |
| Inner Seal # [cntrc] | 417.61000 |
| Discard Thickness | 20.600 MM |
| Discard Thickness | 0.811 IN |
| Nominal Thickness | 22.100 MM |
| Nominal Thickness | 0.870 IN |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 105.400 MM |
| Overall Height | 4.150 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 261.300 MM |
| Rotor Outside Diameter | 10.287 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 63.800 MM |
| Center Hole Diameter | 2.512 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890050537 |
Part Interchanges
- E126-70-038
- E125-70-038
- 5487
- BR5487
- 64 92 880
- R92 880
- 107166
- 5487G
- F29A1102A
- F29Z1102A
- F39A1102KA
- F49Z1102A
- 141758
- PRT1758
- 102870
- 102870E
- 4886488
- 86327
- 86488
- 1229
- AR8533
- AR8533E
- D17704
- E12570038
- E12670038
- YH141758
- 27068
- X50649
- BR1976
- 1066488
- 1066488R
- 66488
- 66488R
- 66488RGS
- 78942033
- 8942033
- 78-42033
- 7842033
- 65405
- 60054123D
CENTRIC 121.65033 Cross Reference
We have 5 alternatives for the 121.65033 by CENTRIC:
Fits Vehicles
- Ford Aerostar (1992-1997)
