CENTRIC 121.63065 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.63065 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 185.500 |
| Weight [cntrc] Kgs | 11.000 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] In | 7.303 |
| Weight [cntrc] Lbs | 24.250 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 0.965 IN |
| Discard Thickness | 24.500 MM |
| Nominal Thickness | 1.028 IN |
| Nominal Thickness | 26.100 MM |
| Overall Height | 67.200 MM |
| Overall Height | 2.646 IN |
| Outside Diameter | 350.000 MM |
| Outside Diameter | 13.780 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 183.900 MM |
| Nominal Drum Diameter | 7.240 IN |
| Bearings Included | No |
| Center Hole Diameter | 72.600 MM |
| Center Hole Diameter | 2.858 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.900 MM |
| Stud/Lug Hole Diameter | 0.665 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890517474 |
CENTRIC 121.63065 Cross References
CENTRIC 121.63065 Fits Vehicles
- Dodge Magnum (2006-2008)
- Chrysler 300 (2014-2016)
- Dodge Charger (2006-2021)
