(888) 312-8812 Login SignupCENTRIC 121.63024 C-Tek Standard Brake Rotor
Tap to view 4 more
$56.57
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.63024 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.63024 Specifications
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 20.000 |
| Product Grade [cntrc] | Standard |
| Vane Style [cntrc] | Straight |
| Notes [cntrc] | Vented Hat |
| Weight [cntrc] Kgs | 9.090 |
| Discard Thickness | 28.580 MM |
| Discard Thickness | 1.125 IN |
| Nominal Thickness | 30.100 MM |
| Nominal Thickness | 1.185 IN |
| Overall Height | 70.600 MM |
| Overall Height | 2.780 IN |
| Outside Diameter | 327.000 MM |
| Outside Diameter | 12.874 IN |
| Mounting Bolt Hole Quantity | 8 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 127.200 MM |
| Center Hole Diameter | 5.008 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Diameter | 17.500 MM |
| Mounting Bolt Hole Diameter | 0.689 IN |
| Hat Finish | Bare |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890139959 |
CENTRIC 121.63024 Cross References
| Brand | Part Number |
|---|---|
| 7054, BD102137 | |
| N/A | BD102137, E126-68-029, 5350, BR5350, 5350G, 3821532, 3821533, 103500, 141397, PRT1397, 4885879, 85879, 433, AR8324, AR8324E, D17073, E8446, E12668029, 121.63024, 99756, 210324C, 210324, 27340, X50114, BR1588, 76283R, 7054, 7054R, 78932024, 8932024, 60040048 |
| PRONTO | BR5350 |
| RAYBESTOS | 7054R |
| WAGNER | BD102137 |
CENTRIC 121.63024 Fits Vehicles
- Dodge W300 Pickup (1974)
- Dodge W350 (1981-1989)
- Dodge W300 (1975-1980)
- Dodge W250 (1986-1993)
- Dodge W200 (1975-1979)
