CENTRIC 121.45046 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For heat capacity and strength
- OE Vane Design & Plate Thickness
- Optimal Surface Finish
- For consistent stopping power
- Low Initial Lateral Run-Out and Disc-Thickness Variation
- For smooth, vibration free stopping
- Precision Balanced
- For vibration free performance
CENTRIC 121.45046 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 5.910 |
| Vane Style [cntrc] | Straight |
| Max Pb Drum Dia [cntrc] In | 7.520 |
| Product Grade [cntrc] | Standard |
| Max Pb Drum Dia [cntrc] Mm | 191.000 |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 13.000 |
| Discard Thickness | 0.630 IN |
| Discard Thickness | 16.000 MM |
| Nominal Thickness | 0.709 IN |
| Nominal Thickness | 18.000 MM |
| Overall Height | 57.100 MM |
| Overall Height | 2.248 IN |
| Outside Diameter | 285.700 MM |
| Outside Diameter | 11.248 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 190.000 MM |
| Nominal Drum Diameter | 7.480 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.835 IN |
| Center Hole Diameter | 72.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.512 IN |
| Stud/Lug Hole Diameter | 13.000 MM |
| Hat Finish | Bare |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890139621 |
CENTRIC 121.45046 Cross References
| Brand | Part Number |
|---|---|
| 1096279, BD125619 | |
| MAGMA PRODUCTS | PMR365063, PMR365057 |
| N/A | BD125619, E126-50-051, 31364, 31160, BR31160, BR31364, 31364G, 31160G, 1096279, 980284, 980284R, 96279R, PRT1706, PRT5569, 141706, 112378, JBR575E, 60080061, E12650051 |
| PRONTO | BR31364 |
| RAYBESTOS | 96279R |
| WAGNER | BD125619, BD126383, BD126383E, BD125254 |
CENTRIC 121.45046 Fits Vehicles
- Mazda 929 (1992-1995)
- Mazda MPV (1993-1998, 2004-2006)
