Name: Reach Cooling 4210598 Radiator
SKU: 4210598
Price: 631.99 USD
Availability: InStock

REACH COOLING part description

Radiator

Product Description

Radiator

Application Summary

09-00 Freightliner Argosy; 08-06 Freightliner B2; 03 Freightliner FL112; 07-06 Freightliner M2 106

Features & Benefits

Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Folded fin edges increase stability and heat disbursement properties.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Our fin edges are folded for increased stability and heat disbursement properties.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

No Shipping Restriction

radiator, complete, industrial, heavy duty, engine cooling, rad, cooling

Product Attributes

Core Material	Aluminum
Inlet Diameter	2.5 IN
Core Height	47 IN
Core Width	26 1/3 IN
Outlet Diameter	2 1/2 IN
Core Thickness	1 7/8 IN
Core Row Quantity	2
Down Flow Or Cross Flow Type	Cross Flow
Tank Material	Plastic PA66-GF30
Inlet Diameter	63.5 mm
Core Width	668.9 MM
Transmission Oil Cooler Included	No
Core Height	1194 MM
Inlet Diameter	63.5 MM
Frame Included	No
Core Thickness	47.625 MM
Outlet Diameter	63.5 MM
Outlet Location	Lower Right
Radiator Cap Included	No
Core Height	1193.8 MM
Core Width	668.858 MM
Core Thickness	47.6 MM
Inlet Location	Upper Left
Outlet Diameter	63.5 MM
Engine Oil Cooler Included	No

Part Interchanges

Fits Vehicles

Freightliner B2 (2006-2008)
Freightliner FL112 (2003-2004)
Freightliner Argosy (1999-2009)
Freightliner M2 106 (2006-2007)
