Centric 120.67066 - Centric Premium Brake Rotor
$14649
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 207.200 |
| Weight [cntrc] Kgs | 11.140 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] In | 8.157 |
| Weight [cntrc] Lbs | 24.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.118 IN |
| Discard Thickness | 28.400 MM |
| Nominal Thickness | 30.000 MM |
| Nominal Thickness | 1.181 IN |
| Hat Finish | Coated |
| Overall Height | 84.300 MM |
| Overall Height | 3.319 IN |
| Outside Diameter | 350.000 MM |
| Outside Diameter | 13.780 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 78.500 MM |
| Center Hole Diameter | 3.091 IN |
| Mounting Bolt Hole Circle Diameter | 139.900 MM |
| Mounting Bolt Hole Circle Diameter | 5.508 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.677 IN |
| Stud/Lug Hole Diameter | 17.200 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890313533 |
Part Interchanges
CENTRIC 120.67066 Cross Reference
We have 4 alternatives for the 120.67066 by CENTRIC:
Fits Vehicles
- Dodge Ram 1500 (2004-2006)
California residents see Prop 65 Warning(s)
