CENTRIC 120.66064 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.66064 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 23.500 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 10.680 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 27.500 MM |
| Discard Thickness | 1.083 IN |
| Nominal Thickness | 29.000 MM |
| Nominal Thickness | 1.142 IN |
| Hat Finish | Painted |
| Overall Height | 54.700 MM |
| Overall Height | 2.154 IN |
| Outside Diameter | 325.200 MM |
| Outside Diameter | 12.803 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 79.100 MM |
| Center Hole Diameter | 3.114 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 13.300 MM |
| Stud/Lug Hole Diameter | 0.524 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890071037 |
CENTRIC 120.66064 Cross References
| Brand | Part Number |
|---|---|
| 580502 | |
| N/A | 0833326, E125-71-069, 02042J2994, 41122, YH145660, 41122G, 15294772, 880502, 55143, 2055143, 90047069, 18A2457, 1770998, E12571069 |
| NEOTEK | 1072036GF |
| Neotek Premium Drums and Rotors | 1072036GF |
| RAYBESTOS | 580502, 580502FZN, 580502PER, 580502R |
| Raybestos Brakes | 580502, 580502FZN, 580502PER, 580502R |
CENTRIC 120.66064 Fits Vehicles
- Saab 9-7x (2008-2009)
- Chevrolet Trailblazer (2006-2009)
