CENTRIC 120.66053 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.66053 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Lbs | 22.500 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 10.230 |
| Discard Thickness | 27.500 MM |
| Discard Thickness | 1.083 IN |
| Nominal Thickness | 1.142 IN |
| Nominal Thickness | 29.000 MM |
| Hat Finish | Painted |
| Overall Height | 54.300 MM |
| Overall Height | 2.138 IN |
| Outside Diameter | 325.000 MM |
| Outside Diameter | 12.795 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 79.000 MM |
| Center Hole Diameter | 3.110 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890361367 |
CENTRIC 120.66053 Cross References
| Brand | Part Number |
|---|---|
| 580023, BD126028 | |
| N/A | BD126028, E125-71-058, BR5507902, 55079, 55079G, 18060665, 25826103, 15054096, 8180606650, 145342, 880023, AR8650, E12571058, 55079HC, 120.66053, 211268, 211268C, 1407-25973, YH145342, X51478, 27279, 2055079, 19960, 90048046, 1771008, 177884, 18A1207, 18A1421A |
| NEOTEK | 107294GF |
| Neotek Premium Drums and Rotors | 107294GF |
| PRONTO | BR5507902 |
| RAYBESTOS | 580023, 580023FZN, 580023PER, 580023R |
| Raybestos Brakes | 580023, 580023FZN, 580023PER, 580023R |
| WAGNER | BD126028E, BD126028 |
CENTRIC 120.66053 Fits Vehicles
- Chevrolet Trailblazer EXT (2002-2006)
- GMC Envoy XL (2002-2006)
- GMC Envoy XUV (2004-2005)
- Chevrolet SSR (2003-2005)
- Chevrolet Trailblazer (2006-2009)
- GMC Envoy (2005-2009)
- Saab 9-7x (2005-2009)
- Buick Rainier (2004-2007)
- Isuzu Ascender (2003-2006)
