(888) 312-8812 Login SignupCENTRIC 120.66043 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $112.62
$9499
Save $17.63
Limited availability at this price!
In Stock
Get as soon as Friday, Oct 9
CENTRIC 120.66043 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.66043 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 24.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 10.910 |
| Discard Thickness | 1.043 IN |
| Discard Thickness | 26.500 MM |
| Nominal Thickness | 29.000 MM |
| Nominal Thickness | 1.142 IN |
| Hat Finish | Painted |
| Overall Height | 85.700 MM |
| Overall Height | 3.374 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 4.630 IN |
| Center Hole Diameter | 117.600 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890036296 |
CENTRIC 120.66043 Cross References
| Brand | Part Number |
|---|---|
| 56830, 580380, BD125656, BD126536 | |
| N/A | BD126536, BD126536E, BD125656, BD125656E, E125-71-048, BR5505702, BR90056202, 55057, 55057G, 41243G, 19255495, 15127537, 15712801, 15727133, 88916862, 19175103, 101005, 145262, 86830, 4886830, 48880380, 880380, 55120, AR8643, E12341, E12571048, 55057HC, 120.66043, 55057GT, 55057DSR, YH145262, 1407-25690, 55057DSL, 27049, 56830P, 580380, 2055057, 19326, 8944043, 1770928, 18A2437, 18A2437A, 18A928, 18A928A, 177860, 90048039 |
| NEOTEK | 107274GF |
| Neotek Premium Drums and Rotors | 107274GF |
| PRONTO | BR5505702 |
| RAYBESTOS | 56830, 56830FZN, 56830PER, 56830R, 56830R2 |
| Raybestos Brakes | 56830, 56830FZN, 56830PER, 56830R |
| WAGNER | BD125656, BD125656E |
CENTRIC 120.66043 Fits Vehicles
- Chevrolet Avalanche 2500 (2002-2006)
- Chevrolet Express 2500 (2003-2009, 2011-2023)
- Chevrolet Express 3500 (2004-2023)
- Chevrolet Silverado 1500 (2004-2005)
- Chevrolet Silverado 1500 HD (2001-2003, 2005-2006)
- Chevrolet Silverado 1500 HD Classic (2007)
- Chevrolet Silverado 2500 (1999-2004)
- Chevrolet Silverado 2500 HD (2005)
- Chevrolet Suburban 2500 (2000-2007)
- GMC Savana 2500 (2003-2023)
- GMC Savana 3500 (2004-2019, 2021-2023)
- GMC Sierra 1500 (2004)
- GMC Sierra 1500 HD (2001-2003, 2005-2006)
- GMC Sierra 1500 HD Classic (2007)
- GMC Sierra 2500 (1999-2004)
- GMC Sierra 2500 HD (2005)
- GMC Yukon XL 2500 (2000-2007)
- Hummer H2 (2003-2009)
