CENTRIC 120.65064 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65064 Specifications
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| Weight [cntrc] Kgs | 14.550 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 32.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 36.300 MM |
| Discard Thickness | 1.429 IN |
| Nominal Thickness | 38.100 MM |
| Nominal Thickness | 1.500 IN |
| Hat Finish | Painted |
| Overall Height | 123.800 MM |
| Overall Height | 4.874 IN |
| Outside Diameter | 327.700 MM |
| Outside Diameter | 12.902 IN |
| Mounting Bolt Hole Quantity | 8 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.850 IN |
| Center Hole Diameter | 123.200 MM |
| Mounting Bolt Hole Circle Diameter | 145.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.709 IN |
| Mounting Bolt Hole Diameter | 12.900 MM |
| Mounting Bolt Hole Diameter | 0.508 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890035985 |
CENTRIC 120.65064 Cross References
| Brand | Part Number |
|---|---|
| 66695, BD125550, F6US1113AA, F6UZ2C026AA, YC2Z1V125AA | |
| BENDIX | 145162 |
| EUCLID | E12332 |
| MERITOR | D4858 |
| N/A | BD125550, E125-70-069, 54053, BRRF107, 54053G, F6US1113AA, F6UZ2C026AA, YC2Z1V125AA, 4886695, 86653, 86695, AR8564, E12570069, 211119, YH145162, 1407-25410, X51329, 27262, 8942064, 78942064, 60054154 |
| NEOTEK | 1071065GF |
| Neotek Premium Drums and Rotors | 1071065GF |
| RAY | 66695 |
| RAYBESTOS | 66695, 66695FZN, 66695R |
| Raybestos Brakes | 66695, 66695FZN, 66695R |
| WAGNER | BD125550 |
CENTRIC 120.65064 Fits Vehicles
- Ford Econoline Super Duty (1996-1999)
- Ford E-450 Super Duty (2003-2007)
- Ford E-450 Econoline Super Duty (2000-2002)
