CENTRIC 120.63069 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.63069 Specifications
Product Attributes
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 12.200 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 6.654 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 169.000 |
| Weight [cntrc] Kgs | 5.550 |
| Discard Thickness | 0.331 IN |
| Discard Thickness | 8.400 MM |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Hat Finish | Painted |
| Overall Height | 60.100 MM |
| Overall Height | 2.366 IN |
| Outside Diameter | 302.000 MM |
| Outside Diameter | 11.890 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 168.000 MM |
| Nominal Drum Diameter | 6.614 IN |
| Bearings Included | No |
| Center Hole Diameter | 80.000 MM |
| Center Hole Diameter | 3.150 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890358756 |
CENTRIC 120.63069 Cross References
| Brand | Part Number |
|---|---|
| 780541, BD126574 | |
| ADVICS | P6R364U |
| ATE BRAKE PRODUCTS | 410360 |
| N/A | 120.63069, BD126574, BD126574E, E125-68-074, BR90075002, 999, 11361, YH245331, 43172, 1407-245331, 53043G, 4615A010, 4615A121, 4615A193, 1606292080, 4743999AA, 4743999AB, 880541, 53043, DDF1737, DDF1763, 90039024, E12568074 |
| NEOTEK | 107098GF |
| Neotek Premium Drums and Rotors | 107098GF |
| PRONTO | BR90075002 |
| RAYBESTOS | 780541, 780541FZN, 780541R, 780541R2 |
| Raybestos Brakes | 780541, 780541FZN, 780541R |
| WAGNER | BD126574E, BD180598, BD126574 |
CENTRIC 120.63069 Fits Vehicles
- Mitsubishi Outlander Sport (2011-2012)
- Chrysler Cirrus (2001-2005, 2007-2010)
- Jeep Patriot (2009-2017)
- Jeep Compass (2009-2017)
- Chrysler 200 (2011-2014)
- Dodge Caliber (2008-2011)
- Dodge Avenger (2008-2014)
- Chrysler Sebring (2007-2010)
- Mitsubishi Outlander (2008-2013)
- Mitsubishi Lancer (2008-2016)
- Mitsubishi RVR (2011-2012)
