(888) 312-8812 Login SignupCENTRIC 120.63035 Centric Premium Brake Rotor
Tap to view 4 more
$2699
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Aug 5
CENTRIC 120.63035 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.63035 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] Mm | 173.200 |
| Max Pb Drum Dia [cntrc] In | 6.819 |
| Weight [cntrc] Kgs | 4.770 |
| Weight [cntrc] Lbs | 10.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 10.400 MM |
| Discard Thickness | 0.409 IN |
| Nominal Thickness | 11.800 MM |
| Nominal Thickness | 0.465 IN |
| Hat Finish | Painted |
| Overall Height | 51.400 MM |
| Overall Height | 2.024 IN |
| Outside Diameter | 270.200 MM |
| Outside Diameter | 10.638 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 171.800 MM |
| Nominal Drum Diameter | 6.764 IN |
| Bearings Included | No |
| Center Hole Diameter | 73.600 MM |
| Center Hole Diameter | 2.898 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.555 IN |
| Stud/Lug Hole Diameter | 14.100 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890043027 |
CENTRIC 120.63035 Cross References
| Brand | Part Number |
|---|---|
| 76316, BD125306, BD180019 | |
| N/A | BD180019, BD125306, BD125306E, E125-68-040, 6491120, 6491740, 5356, 5356G, 107031, 107043, 4779018, 4779111AA, 4779111AB, 4779111AC, 4582225, 141849, 86316, 86831, 4886316, 475, AR8335, AR8346, D17575, E12568040, 5356HC, 120.63035, 018111AB, 130975, 5356DSR, 5356DSL, YH141849, 27183, X50688, BR1891, 19776, 8932035, 8932046, 18A550, 90040012 |
| PRONTO | BR535602 |
| RAYBESTOS | 76316, 76316FZN, 76316R |
| Raybestos Brakes | 76316, 76316FZN, 76316R |
| WAGNER | BD125306, BD125306E |
CENTRIC 120.63035 Fits Vehicles
- Eagle Vision (1993-1997)
- Chrysler Intrepid (1993-1996, 1998-2004)
- Dodge Intrepid (1993-2004)
- Chrysler New Yorker (1994-1996)
- Chrysler LHS (1994-1997, 1999-2001)
- Chrysler Concorde (1993-2004)
- Chrysler 300M (1999-2004)
CENTRIC 120.63035 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 120.63035 Questions & Answers
No questions yet
Be the first to ask a question about this product!
