CENTRIC 120.46047 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.46047 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 3 |
| Max Pb Drum Dia [cntrc] In | 6.654 |
| Weight [cntrc] Lbs | 9.500 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Max Pb Drum Dia [cntrc] Mm | 169.000 |
| Weight [cntrc] Kgs | 4.320 |
| Discard Thickness | 8.400 MM |
| Discard Thickness | 0.331 IN |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Hat Finish | Painted |
| Overall Height | 2.370 IN |
| Overall Height | 60.200 MM |
| Outside Diameter | 261.900 MM |
| Outside Diameter | 10.311 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 167.900 MM |
| Nominal Drum Diameter | 6.610 IN |
| Bearings Included | No |
| Center Hole Diameter | 90.000 MM |
| Center Hole Diameter | 3.543 IN |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.496 IN |
| Stud/Lug Hole Diameter | 12.600 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890041696 |
CENTRIC 120.46047 Cross References
| Brand | Part Number |
|---|---|
| 76627, BD125464 | |
| N/A | 0802641, 0832641, 0832650, BD125464, BD125464E, E125-51-052, 64 75 600, 64 75 720, 6475600, 6475720, 31147, 106826, 31147G, MR493489, MB895200, MB928202, MB928716, 145047, 4886627, 86627, JBR772, D17721, E12551052, 120.46047, 31147DSR, 31147DSL, YH145047, 25557, X50943, 76627, 76627P, DDF1410, 19870, 90072028 |
| NEOTEK | 106826GF |
| Neotek Premium Drums and Rotors | 106826GF |
| PRONTO | BR3114702 |
| RAYBESTOS | 76627FZN, 76627R |
| Raybestos Brakes | 76627FZN, 76627R |
| WAGNER | BD125464, BD125464E |
CENTRIC 120.46047 Fits Vehicles
- Eagle Talon (1995-1998)
- Mitsubishi Lancer (2004-2006)
- Mitsubishi Outlander (2005-2006)
- Dodge Stratus (2001-2005)
- Dodge Avenger (1995-2000)
- Chrysler Sebring (1995-2005)
- Mitsubishi Galant (1999-2003)
- Mitsubishi Eclipse (1994-2005)
