CENTRIC 120.46032 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.46032 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 8 |
| Weight [cntrc] Lbs | 14.500 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 6.590 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.882 IN |
| Discard Thickness | 22.400 MM |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24.000 MM |
| Hat Finish | Painted |
| Overall Height | 45.300 MM |
| Overall Height | 1.783 IN |
| Outside Diameter | 276.000 MM |
| Outside Diameter | 10.866 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.492 IN |
| Stud/Lug Hole Diameter | 12.500 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890029694 |
CENTRIC 120.46032 Cross References
| Brand | Part Number |
|---|---|
| 96891, 96153, BD125141, BD125348 | |
| N/A | BD125141, BD125348, 0832501, 0832502, 0832673, 0832708, 0832715, 0832857, 6475410, 6475710, 6475790, 31003, 31002, 31224, 106809, 106822, 31002G, 31003G, 31224G, MR44817, MR449817, MB618344, MB668535, MB858799, MB895097, MB928318, MB928319, MR389727, MR403943, MR449660, MR449818, AW338588, AW351056, 141574, 141864, 141865, 86891, 86153, 4886153, 4886891, 336, JBR583, JBR775, D17631, 1.3027.2.5, 1302725, MB271V, 31003GT, YH141574, X50659, X50660, 25544, 96153, 96153P, 96891, DDF1393, 19782, 8916028, 8926010, 90072015 |
| NEOTEK | 106809GF |
| Neotek Premium Drums and Rotors | 106809GF |
| RAYBESTOS | 96153R |
| Raybestos Brakes | 96153R |
| WAGNER | BD61983, BD125348 |
CENTRIC 120.46032 Fits Vehicles
- Mitsubishi Galant (1999-2000)
- Mitsubishi Eclipse (1992-2000)
- Mitsubishi 3000GT (1991-1999)
- Plymouth Laser (1993-1994)
- Eagle Talon (1993-1997)
- Dodge Stealth (1991-1996)
- Mitsubishi Diamante (1992-2004)
