CENTRIC 120.45034 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.45034 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 1 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 3.860 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 8.500 |
| Discard Thickness | 0.630 IN |
| Discard Thickness | 16.000 MM |
| Nominal Thickness | 18.000 MM |
| Nominal Thickness | 0.709 IN |
| Hat Finish | Painted |
| Overall Height | 45.000 MM |
| Overall Height | 1.772 IN |
| Outside Diameter | 234.700 MM |
| Outside Diameter | 9.240 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 55.000 MM |
| Center Hole Diameter | 2.165 IN |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.512 IN |
| Stud/Lug Hole Diameter | 13.000 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890041368 |
CENTRIC 120.45034 Cross References
| Brand | Part Number |
|---|---|
| 96213, BD61998 | |
| N/A | BD61998, 0832425, 64 74 410, 6474410, 3299, 3299G, 106605, NA013325XB, NAO13325XA, B5Y23325XC, NA013325A, NA013325XC, SA013325X, NA013325X, NA013325XA, NA013325XD, 141717, 4886213, 86213, 366, JBR543, D17638, 120.45034, 1.2645.2.4, 1264524, MZ711V, 3299GT, YH141717, 25406, X50630, BR1675, 96213, DDF497, DF2719, 8914034, 90080022 |
| RAYBESTOS | 96213R |
| Raybestos Brakes | 96213R |
| WAGNER | BD61998 |
CENTRIC 120.45034 Fits Vehicles
- Mazda Miata (1990-1993)
