CENTRIC 120.40027 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.40027 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Lbs | 9.750 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 4.430 |
| Discard Thickness | 7.500 MM |
| Discard Thickness | 0.295 IN |
| Nominal Thickness | 9.000 MM |
| Nominal Thickness | 0.354 IN |
| Hat Finish | Painted |
| Overall Height | 61.200 MM |
| Overall Height | 2.409 IN |
| Outside Diameter | 11.102 IN |
| Outside Diameter | 282.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 170.100 MM |
| Nominal Drum Diameter | 6.697 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.200 MM |
| Center Hole Diameter | 2.764 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.504 IN |
| Stud/Lug Hole Diameter | 12.800 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890039686 |
CENTRIC 120.40027 Cross References
| Brand | Part Number |
|---|---|
| 96178, BD125221 | |
| ATE BRAKE PRODUCTS | 409132 |
| N/A | BD125221, 0832755, E125-45-032, 64 71 100, 6471100, 42510SP0000, 31105, 31105G, 106220, 5862029730, 5862029740, 42510SX0000, 42510SFE000, 141514, 4886178, 86178, 246, JBR529, D17683, E12545032, 1192954, 1.1929.5.4, 120.40027, YH141514, X50908, 25191, BR1742, 96178, DDF672, DF4005, 19787, 8908028, 90059041 |
| NEOTEK | 106220GF |
| Neotek Premium Drums and Rotors | 106220GF |
| RAYBESTOS | 96178R |
| Raybestos Brakes | 96178R |
| WAGNER | BD125221 |
CENTRIC 120.40027 Fits Vehicles
- Honda Odyssey (1995-1998)
- Acura RL (1996-1998)
- Acura Legend (1991-1995)
- Isuzu Oasis (1996-1999)
