CENTRIC 120.39005 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.39005 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 13.860 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 6.300 |
| Discard Thickness | 22.800 MM |
| Discard Thickness | 0.898 IN |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24.000 MM |
| Hat Finish | Painted |
| Overall Height | 64.300 MM |
| Overall Height | 2.531 IN |
| Outside Diameter | 263.500 MM |
| Outside Diameter | 10.374 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 68.200 MM |
| Center Hole Diameter | 2.685 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890031086 |
CENTRIC 120.39005 Cross References
| Brand | Part Number |
|---|---|
| 96100, BD60581 | |
| N/A | 0831198, BD60581, 64 21 130, 6421130, 34027, 34027G, 270738, 2707381, 2707388, 1229349, 12293494, 1205781, 12057816, 1229344, PRT1407, PRT5503, 145503, 141407, 144453, 4886100, 86100, 299, EBR081, D9266, 1.6005.2.4, 1600524, VV051V, YH141407, 25226, X50824, BR1403, DDF163, 142662, 90027004 |
| RAYBESTOS | 96100, 96100R |
| Raybestos Brakes | 96100, 96100R |
