(888) 312-8812 Login SignupCENTRIC 320.34071F Centric GCX Rotor with Full Coating
$9799
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
CENTRIC 320.34071F Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating
Application Summary
BMW 535i 2010-2008, 545i 2005-2004, 550i 2010-2006, 645Ci 2005-2004, 650i 2010-2006
C-Tek; Centric; Standard brake rotor; brake rotor; break rotor; rotors; rotor
GCX FC BRAKE ROTOR
CENTRIC 320.34071F Specifications
Product Attributes
| Discard Thickness | 28.400 MM |
| Nominal Thickness | 1.181 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 77.100 MM |
| Outside Diameter | 13.701 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 79.000 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.600 MM |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 1 |
| Notes [cntrc] | Vented Hat |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 10.000 |
| Weight [cntrc] Lbs | 22.000 |
CENTRIC 320.34071F Fits Vehicles
- BMW 645Ci (2004-2005)
- BMW 545i (2004-2005)
- BMW 650i (2006-2010)
- BMW 550i (2006-2010)
- BMW 535i (2008-2010)
CENTRIC 320.34071F Manufacturer Information
Formed in 2017, Centric® brings two of the industry’s leading undercar parts manufacturers, AP Emissions Technologies and Centric Brakes, under one brand. The merger combines more than 90 years’ worth of experience in aftermarket performance exhaust solutions with market leadership in brakes and chassis systems, resulting in an extensive portfolio of undercar components made available to distribution partners worldwide. From brake discs to catalytic converters, APC-Centric products make use of high-quality materials precision engineering to provide reliable performance at a reasonable cost to the customer. Also, as part of the larger APC Automotive Technologies group, APC-Centric has the competitive advantage of vertically-integrated supply chain and access to a global network of R&D, testing, and manufacturing facilities and customer support channels.
