(888) 312-8812 Login SignupCENTRIC 320.04006F Centric GCX Rotor with Full Coating
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 320.04006F Part Description
CENTRIC 320.04006F Specifications
Product Attributes
| Hat Id [cntrc] Mm | 124.500 |
| Hat Id [cntrc] In | 4.902 |
| Weight [cntrc] Lbs | 17.950 |
| Misc Holes [cntrc] | 5 |
| OEM Vane Count [cntrc] | 93 |
| Weight [cntrc] Kgs | 8.160 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Pillar |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Discard Thickness | 1.004 IN |
| Discard Thickness | 25.500 MM |
| Nominal Thickness | 28.000 MM |
| Nominal Thickness | 1.102 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 45.700 MM |
| Overall Height | 1.799 IN |
| Outside Diameter | 305.000 MM |
| Outside Diameter | 12.008 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.323 IN |
| Center Hole Diameter | 59.000 MM |
| Mounting Bolt Hole Circle Diameter | 98.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.858 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
CENTRIC 320.04006F Fits Vehicles
- Fiat 500L (2014-2020)
