(888) 312-8812 Login SignupCENTRIC 125.61130 Centric Premium High Carbon Alloy Brake Rotor
*Representative image - actual part not displayed
$12449
Limited availability at this price!
5 Day Lead Time
Get it by Wednesday, Dec 24
CENTRIC 125.61130 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Application Summary
Ford Edge 2022-2019
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
High Carbon Alloy; Centric Parts; CentricParts; Centric Brake Rotors CentricParts Break Rotor; StopTech; Stop Tech; StopTech Hig Carbon Rotor
CENTRIC 125.61130 Specifications
Product Attributes
| Discard Thickness | 30.500 MM |
| Nominal Thickness | 1.260 IN |
| Hat Finish | Coated |
| Overall Height | 52.500 MM |
| Outside Diameter | 345.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.500 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.618 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] In | 6.232 |
| Hat Id [cntrc] Mm | 158.300 |
| Misc Holes [cntrc] | 0 |
| OEM Vane Count [cntrc] | 53 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 12.680 |
| Weight [cntrc] Lbs | 27.950 |
Additional Information
| NAFTA Preference Criterion Code | B |
| UPC | 00889590371864 |
CENTRIC 125.61130 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 682510, 682510R |
CENTRIC 125.61130 Fits Vehicles
- Ford Edge (2019-2022)
CENTRIC 125.61130 Cross References
We have 2 alternatives for the 125.61130 by CENTRIC:
