Name: Rancho RS55845 RS5000X Montante de Suspension (Strut)
SKU: rs55845
Price: 184.49 USD
Availability: InStock

RANCHO part description

Product Description

Suspension Strut

Features & Benefits

IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
STRONG AND DURABLE -- Features a nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, application-specific sintered iron piston for enhanced structural integrity and polyvinyl protective boot
HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
REDUCES FADE -- Nitrogen gas pressurized to 60 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty

Product Attributes

Body Type	SS7
Compressed Length	15.61 IN
Travel Length	5.57 in
Mounting Hardware Included	Yes
Grade Type	Performance
Extended Length	21.18 in
Lower Mount Type	Cross Pin
Upper Mount Type	Stud
Gas Charged	Yes
Body Diameter	2.13 IN
Body Length	14.8 IN
Adjustable Damping	No
Dust Shield Included	No
Internal Rebound Spring	No
Includes Bump Stop	No
Internal Rebound Bumper	Yes
Finish	Painted
Hydraulic Lockout	No
Parts Pack(s)	P01763, P01577
Compressed Length	396.5 MM
Extended Length	538 MM
Travel Length	141.5 MM
Body Length	375.9 MM
Body Diameter	54.1 MM

Additional Information

Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708803000
Harmonized Tariff Code (Schedule B)	8708801600
Harmonized Tariff Code (HTS)	8708801600
MSDS Sheet Number	01164
UPC	00039703012850
UNSPSC	25172007
