(888) 312-8812 Login SignupATE BRAKE PRODUCTS 409163 ATE Original Rear Disc Brake Rotor 409163 for Lexus, Toyota
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
ATE BRAKE PRODUCTS 409163 Part Description
Manufacturer
Product Description
ATE Original Rear Disc Brake Rotor 409163 for Lexus, Toyota
Features & Benefits
- Application specific design is engineered to tighter tolerances
- Protective coating ensures long lasting corrosion resistance
- High carbon brake disc optimize durability and prevents brake judder and noise
- Use of state of the art original replacement part materials in the production of the rotors
ATE BRAKE PRODUCTS 409163 Specifications
Product Attributes
| Outside Diameter | 259.00 MM |
| Inside Diameter | 156.20 MM |
| Nominal Thickness | 9.00 MM |
| Discard Thickness | 7.50 MM |
| Solid Or Vented Type Rotor | Solid |
| Surface Type | Smooth |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Overall Height | 30.20 MM |
| Material | High-carbon |
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Stud/Lug Hole Circle Diameter | 100.00 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.50 MM |
| Center Hole Diameter | 55.00 MM |
| Directional or Non-Directional Brake Surface | Non-Directional |
Additional Information
| Country of Origin (Primary) | IT |
| EU | |
| UPC | 04006633337342 |
ATE BRAKE PRODUCTS 409163 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 18A2635A |
| Aimco | 10155159 |
| Beck/Arnley | 083-3354 |
| Bendix | PRT5854 |
| Bosch | 0 986 479 721, 50011484 |
| Brembo | 08.A534.30, 08.A534.31 |
| Centric Parts | 120.44165 |
| Delphi | BG4201 |
| Hella | 55240PRO, 8DD 355 116-901 |
| N/A | 4243102200 |
| Raybestos Brakes | 580704, 580704R |
| TRW | DF6145 |
| Textar | 92224003 |
| Toyota | 4243112310 |
| Valeo | 197491 |
| Wagner Brake | BD126558 |
| Winhere | 441804 |
ATE BRAKE PRODUCTS 409163 Fits Vehicles
- Toyota Matrix (2009-2013)
- Toyota Corolla (2009-2019, 2022)
- Toyota Prius AWD-e (2019-2022)
- Toyota Prius Prime (2017-2022)
- Toyota Prius Plug-In (2012-2015)
- Lexus CT200h (2011-2013)
- Toyota Prius (2010-2022)
