(888) 312-8812 Login SignupCENTRIC 401.58003 Premium Hub and Bearing Assembly, With ABS Tone Ring / Encoder
Tap to view 4 more
*Representative image - actual part not displayed
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 401.58003 Part Description
CENTRIC 401.58003 Specifications
Product Attributes
| Spline Quantity | 27 |
| Wheel Stud Size | 12.000 MM |
| Wheel Pilot Diameter | 64.960 MM |
| Brake Pilot Diameter | 69.950 MM |
| Wheel Stud Quantity | 5 |
| Wheel Studs Included | Yes |
| Flange Diameter | 5.315 IN |
| Bolt Circle Diameter [cntrc] In | 4.331 |
| Bolt Circle Diameter [cntrc] Mm | 110.000 |
| Inner Mount Pilot [cntrc] In | 3.305 |
| Inner Mount Pilot [cntrc] Mm | 83.950 |
| Mounting Hole Qty [cntrc] | 4 |
| Mounting Thread Pitch [cntrc] Mm | 1.750 |
| Mouting Thread Size [cntrc] Mm | 12.000 |
| Notes [cntrc] | Magnetic Encoder; 1 Misc Hole M10-1.25 |
| Off-set [cntrc] In | 1.657 |
| Off-set [cntrc] Mm | 42.100 |
| Thread Pitch To Wheel Mounting [cntrc] Mm | 1.250 |
| Product Grade [cntrc] | Premium |
| Wheel Pilot Diameter | 2.557 IN |
| Brake Pilot Diameter | 2.754 IN |
CENTRIC 401.58003 Cross References
CENTRIC 401.58003 Fits Vehicles
- Jeep Compass (2017-2019, 2021)
