(888) 312-8812 Login SignupNTN WE60800 Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
Tap to view 9 more
$24599
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
NTN WE60800 Part Description
Manufacturer
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
NTN WE60800 Specifications
Product Attributes
| Spline Quantity | 33 |
| Flange Bolt Hole Quantity | 3 |
| Wheel Pilot Diameter | 2.557 IN |
| Brake Pilot Diameter | 2.576 IN |
| Wheel Stud Quantity | 5 |
| Flange Shape | Modified Triangle |
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Tone Ring |
| Drive Type | Driven |
| Flange Offset | 1.535 IN |
| Bolt Circle Diameter | 4.331 IN |
| Knuckle Bolt Hole Size | M12X1.75 |
| Wheel Stud Size | M12X1.5 MM |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (Schedule B) | 8708995800 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810608007 |
NTN WE60800 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | FW299, 513206 |
| Autopart International | 141149181 |
| CENTRIC | 402.62011 |
| Centric Parts | 402.62011, 402.62011E |
| DT Components | 513206 |
| Drive Tech America | NT513203 |
| DuraGo | 29513206 |
| Fenco | WH513206 |
| GMB | 7990297 |
| GSP | 104206 |
| General Motors | 12413197, 12413218, 7467601, 12413217, 22715554, 19259801 |
| MOOG Chassis Products | 513206 |
| MPA | WH513206 |
| Magneti Marelli | 1AMH513206 |
| Mevotech | TXF513206, H513206 |
| Parts Master | PM513206 |
| Parts Plus | P513206 |
| Power Train | PT513206 |
| Precision Bearing | 513206 |
| Raybestos Brakes | 713206 |
| SKF | BR930433 |
| Schaeffler | 102040, FW9206 |
| Timken | HA590086 |
NTN WE60800 Fits Vehicles
- Pontiac G5 (2007-2010)
- Pontiac Pursuit (2005-2006)
- Chevrolet HHR (2006-2011)
- Chevrolet Cobalt (2005-2010)
- Saturn Ion (2004-2007)
