Name: Reach Cooling 41-922 Radiator
SKU: 41922
Availability: OutOfStock

REACH COOLING part description

Product Description

Radiator

Application Summary

Dodge:79-87 D100/ D150/79-80 D200/81-87 D250/79-80 Ramcharger/86-87 W100/79-87 W150; Plymouth:79-80 Trailduster

Features & Benefits

Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Folded fin edges increase stability and heat disbursement properties.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our fin edges are folded for increased stability and heat disbursement properties.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Core Height	460.4 MM
Outlet Location	Lower Right
Inlet Header Width	2.312 IN
Outlet Diameter	38 MM
Core Width	25 1/8 IN
Core Material	Aluminum
Tank Material	Aluminum
Transmission Oil Cooler Included	Yes
Transmission Oil Cooler Distance between Fittings	305 MM
Outlet Header Width	58.74 MM
Inlet Diameter	1 1/2 IN
Engine Oil Cooler Included	No
Core Thickness	1 IN
Down Flow Or Cross Flow Type	Down Flow
Fitting Connection Type	Pipe connect
Inlet Header Length	652.5 MM
Outlet Header Length	25.625 IN
Inlet Location	Upper Right
Radiator Cap Included	No
Transmission Oil Cooler Type	Concentric
Core Row Quantity	2
Trans Cooler Adapter Fittings Included (True/False)	False
Core Thickness	25.4 MM
Core Width	638.175 MM
Inlet Diameter	38.1 mm
Outlet Header Width	58.724 mm
Transmission Oil Cooler Distance between Fittings	12 IN
Outlet Header Length	650.875 mm
Outlet Header Width	2.312 IN
Inlet Header Width	58.724 mm
Core Thickness	26 MM
Inlet Header Width	58.74 MM
Inlet Header Length	652.449 mm
Inlet Diameter	38.1 MM
Outlet Diameter	1.5 IN
Core Height	460.375 MM
Core Height	18 1/8 IN
Core Width	638.2 MM
Inlet Header Length	25 11/16 IN
Outlet Diameter	38.1 MM
Transmission Oil Cooler Distance between Fittings	304.8 MM
Outlet Header Length	650.88 MM

Part Interchanges

Fits Vehicles

Plymouth Trailduster (1979-1980)
Dodge W200 (1979-1980)
Dodge W150 (1979-1987)
Dodge W100 (1986-1987)
Dodge Ramcharger (1979-1980)
Dodge D250 (1981-1987)
Dodge D200 (1979-1980)
Dodge D150 (1979-1987)
Dodge D100 (1979, 1985-1987)
