FRAM CH11277 Part Description
Manufacturer
Product Description
FRAM, CH11277, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
Cartridge Oil Filter
FRAM CH11277 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 4.350 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.080 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 0.748 IN |
| O-ring (1) Outside Diameter | 0.866 IN |
| O-ring (1) Thickness | 0.118 IN |
| O-ring (2) Inside Diameter | 0.551 IN |
| O-ring (2) Outside Diameter | 0.669 IN |
| O-ring (2) Thickness | 0.118 IN |
| O-ring Inside Diameter | 2.913 IN |
| O-ring Outside Diameter | 3.050 IN |
| O-ring Thickness | 0.137 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.560 in |
| Outer Diameter Top | 2.560 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 1.080 in |
| Torque Nut | No |
| Washable | No |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100555427 |
| UNSPSC | 15121501 |
FRAM CH11277 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 041-0867 |
| Carquest | 94026 |
| Carquest Premium Filters | 94026 |
| Champ | P1013 |
| Chrysler | 68091826AA, 68091827AA |
| ECOGUARD | X10382 |
| Fiat | K68091826AA, K68091827AA |
| Fleetguard | LF4000 |
| Hastings | LF723 |
| Hengst | E11H D204 |
| Jura Filtration | SO7217 |
| Knecht | OX153/7D2 ECO |
| LUBER-FINER | P1013 |
| Land Rover | LR022896 |
| MAHLE | OX153/7D2, OX 153 7D2 |
| MANN-HUMMEL FILTERS | HU7010z |
| Mann-Filter | HU7010Z, HU718/4Y |
| Mercedes-Benz | 112 184 04 25, 112 184 0425, 651 108 0009, 651 180 0109, 651 180 0309, 651 184 0025 |
| NAPA Gold Filters | 100026 |
| Nissan | 15209-HG00A |
| PARTS PLUS | P9984EX |
| PREMIUM GUARD | PG9984EX |
| PUREPRO | PL91013 |
| Purolator | L21405 |
| STP | S11277 |
| STP Filters | S11277, S11277XL |
| Service Champ | WP1013 |
| WIX FILTERS | WL10026 |
| Warner | WP1013 |
| Warner Filters | WP1013 |
| Wix | WL10026, WL7470 |
FRAM CH11277 Fits Vehicles
- Freightliner Sprinter 3500 (2014-2017)
- Freightliner Sprinter 2500 (2014-2017)
- Suzuki Aerio (2002)
- Mercedes-Benz GLE300d (2016-2017)
- Mercedes-Benz E250 (2014-2016)
- Mercedes-Benz ML250 (2015)
- Mercedes-Benz GLK250 (2013-2015)
- Mercedes-Benz Sprinter 3500 (2014-2017)
- Mercedes-Benz Sprinter 2500 (2014-2017, 2020-2022)
