MAIN FILTER part description

Technical Specifications

Outside Diameter Top 5.06
Outside Diameter Bottom 5.06
Thread Size 1.5
Threads 16 UNF
ADBV NO
Burst Pressure 261
Collapse Pressure 72.5
Flow Rate GPM 40 GPM
Operating Temp Min F -13
Operating Temp Max F 248
Flow Direction Outside-In
Gasket Material Buna
Fluid Type HH / HL / HM / HV
Beta Ratio 1 2/10
Micron 1 10

Features & Benefits

  • Interchange/replacement for OEM UFI p/n ESF22NCC
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0272699 replaces OEM ESF22NCC by UFI and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products
  • Compatible with OEM filter in fit, form and function
  • Main Filter MF0272699 replaces OEM ESF22NCC by UFI and is compatible in fit, form and function.
  • Images may be a general representations of products
  • Buy hydraulic filters direct from the manufacturer
  • Images may be a general representations of products

Features & Benefits

  • Interchange/replacement for OEM UFI p/n ESF22NCC
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0272699 replaces OEM ESF22NCC by UFI and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products

Product Attributes

Bypass No
Handle No
Filter Area (sq. in.) 671
Height (in.) 10.94
ADBV No
Beta Ratio 1 2/10
Burst Pressure 261
Wrap No
Collapse Pressure 72.5
Gasket Material Buna
Flow Direction Outside-In
Flow Rater 40 GPM
Maximum Operating Temperature 248 Deg Fahrenheit
Minimum Operating Temperature -13 Deg Fahrenheit
Micron Rating 10
Thread Size 1.5
Fluid Type HH / HL / HM / HV
Product Media Cellulose
Outside Diameter (Top) 5.06 in.
Thread Type UNF

Part Interchanges

MAIN FILTER MF0272699 Cross Reference

We have 1 alternatives for the MF0272699 by MAIN FILTER:
