Name: Main Filter MF0506859 Aftermarket Replacement Hydraulic Filter with 20 Micron Rating, Glass, Outside-In Flow
SKU: mf0506859
Price: 161.49 USD
Availability: InStock

MAIN FILTER part description

Technical Specifications

Outside Diameter Top	2.717
Inide Diameter Top	1.347
Outside Diameter Bottom	2.717
Collapse Pressure	3045
Operating Temp Min F	-13
Operating Temp Max F	248
Capacity gr	60.213594
Filter Area sq in	671
Flow Direction	Outside-In
Gasket Material	Viton
Fluid Type	HH / HL / HM / HV
Beta Ratio 1	200/20.7
Beta Ratio 2	1000/26.6
Micron 1	25

Features & Benefits

Interchange/replacement for OEM PALL p/n HC2217FDT14H
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0506859 replaces OEM HC2217FDT14H by PALL and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products
Interchange/replacement for OEM PALL p/n HC2217FDT14H
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.

Features & Benefits

Interchange/replacement for OEM PALL p/n HC2217FDT14H
Compatible with OEM filter in fit, form and function
All of our elements are manufactured following ISO specifications.
Buy hydraulic filters direct from the manufacturer
Built using Quality Components with strict quality control.
Main Filter MF0506859 replaces OEM HC2217FDT14H by PALL and is compatible in fit, form and function.
All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
Images may be a general representations of products

Product Attributes

Height (in.)	13.97
Bypass	No
Wrap	No
Outside Diameter (Top)	2.72 in.
Product Media	Glass
Inside Diameter (Top)	1.35 in.
Collapse Pressure	3045
Minimum Operating Temperature	-13 Deg Fahrenheit
Outside Diameter (Bottom)	2.72 in.
Filter Area (sq. in.)	671
Handle	No
Maximum Operating Temperature	248 Deg Fahrenheit
Gasket Material	Viton
Micron Rating	20
Fluid Type	HH / HL / HM / HV
Dust Holding Capacity	60.21 grams
Beta Ratio 2	1000/26.6
Beta Ratio 1	200/20.7
Flow Direction	Outside-In

Part Interchanges

Pall HC2217FDT14H

MAIN FILTER MF0506859 Cross Reference

We have 1 alternatives for the MF0506859 by MAIN FILTER:

PALL HC2217FDT14H
