Standard Ignition S2482 - Multi Function Connector
- Part Number
- S2482
- Manufacturer
- STANDARD IGNITION
- Description
-
Multi Function Connector
details
$4149
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
STANDARD IGNITION part description
Product Description
Multi Function Connector
Features & Benefits
- Protective Tubing Included
- Each part has high-quality direct replacement electrical connector that eliminates the need for a harness, replacing only the damaged connector, for a cost effective repair solution
- The terminals are manufactured with high grade materials such as copper alloy, brass, and phosphor bronze.
- The Housing is fabricated using polyamide resins. All of the materials together provide the connectors with prolonged life and superior performance in harsh environments.
- All electrical connectors are 100% tested for proper mechanical and electrical fit, form and function.
- Offering thousands of high-quality pigtails and sockets for nearly every electrical job.
Product Attributes
| Attachment Method | Push On |
| Bend Angle (Deg.) | 0 |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Contact Terminal Material | Metal |
| Dust Shield Included | No |
| Length - Inches | 1.25 |
| Material | Plastic |
| Number Of Splice Connectors Includ | 8 |
| Number of Wires | 8 |
| Splice Connectors Included | Yes |
| Terminal Gender | Female |
| Terminal Quantity | 8 |
| Terminal Type | Blade |
| Water Resistant | Yes |
| Weatherproof Sealed | Yes |
| Wire Gauge (ga) | 18 |
| Wire Quantity | 8 |
| Wiring Harness Included | Yes |
| Wiring Harness Length (in) | 13.25 |
| Wiring Harness Length (mm) | 336.55 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8536908585 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00033086559896 |
Part Interchanges
Fits Vehicles
- Ford Fusion (2013-2020)
- Ford Escape (2013-2020)
- Lincoln MKX (2016)
- Ford EcoSport (2018-2019)
- Lincoln Continental (2017)
- Lincoln MKC (2015-2017)
- Ford Edge (2015-2022)
- Ford Mustang (2015-2017)
- Ford Transit Connect (2014-2018)
- Lincoln MKZ (2013-2020)
- Ford C-Max (2013-2018)
- Ford Fiesta (2011-2019)
- Ford Focus (2012-2018)
- Ford Windstar (2003)
