DELPHI TC6537 Part Description
Manufacturer
Product Description
Ball Joint
Features & Benefits
- Delphi ball joints manufactured with high quality forgings for increased strength and smooth operation
- Ball joints utilize chloroprene rubber boots which improves durability, preventing premature failure
- Delphi machines to micron tolerances to guarantee durability and smooth joint operation
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC6537 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | SAE1045, 40Cr |
| Color | Black |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard Replacement |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 24.80 MM |
| Washers Included | Yes |
| Nuts Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greaseable | Yes |
| Stud Thread Length | 18.5 MM |
| Stud Type | Tapered |
| Mounting Type | Bolt-In |
| Distance Between Mounting Holes | 59.00 MM |
| Dust Boot Material | Rubber |
| Mounting Bolt Head Diameter | 11.90 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Thread Pitch | 1.25 MM |
| Mounting Bolt Thread Length | 24.80 MM |
| Tapered Stud | Yes |
| Stud Tapered End 2 Diameter | 18.3 MM |
| Stud Tapered End 1 Diameter | 16.2 MM |
| Mounting Bolt Length | 0.980 IN |
| Stud Thread Length | 0.73 IN |
| Mounting Bolt Head Diameter | 0.470 IN |
| Mounting Bolt Thread Length | 0.980 IN |
| Stud Tapered End 2 Diameter | 0.72 IN |
| Stud Tapered End 1 Diameter | 0.64 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Country of Origin (Primary) | CN |
| UPC | 00689604350737 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DELPHI TC6537 Cross References
DELPHI TC6537 Fits Vehicles
- Mercury Bobcat (1975-1980)
- Ford Pinto (1974-1980)
- Ford Mustang II (1974-1978)
