Need help? We're here!
(888) 312-8812 Login SignupDELPHI TA5514 Tie Rod End
Tap to view 5 more
$3549
Limited availability at this price!
In Stock
Get it by Friday, Dec 26
DELPHI TA5514 Part Description
DELPHI TA5514 Specifications
Product Attributes
| Position(s) | Inner |
| Item Grade | Standard Replacement |
| Length | 294.50 MM |
| Color | Black and Gray |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Dust Boot Included | No |
| Width | 37 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 14.00 MM |
| Height | 294.50 MM |
| Housing Material | Steel |
| Tube Diameter | 0.571 IN |
| Tube Diameter | 14.50 MM |
| Adjustable | No |
| Greaseable | No |
| Weight | 1.1 lb |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Grade | Premium |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| End 1 Thread Pitch | 1 MM |
| Length - Stud Center to End | 254.00 MM |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 16.00 MM |
| Grade Type | Standard |
| Locking Nut Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| Length - Stud Center to End | 10.000 IN |
| End 1 Thread Diameter | 0.630 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708947550 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604313244 |
| VMRS Code | 015004070 |
| UNSPSC | 25174205 |
DELPHI TA5514 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-4448 |
| MOOG Chassis Products | EV347 |
| Datsun/Nissan | 48521-65F01 |
| Dorman | 535-120 |
| TRW | JAR1177 |
| N/A | MEV347, GEV347 |
DELPHI TA5514 Fits Vehicles
- Nissan 240SX (1995-1998)
DELPHI TA5514 Customer Reviews
No reviews yet
Be the first to review this product!
