WABCO 9253940110 - Air Brake Spring Brake Actuator - Tristop Series, Double Diaphragm, 30/36
$12649
MSRP: $211.60
Save: $85.11
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Port Angle | 135° |
| Max. operating pressure | 10.0 bar |
| Temperature Range | -40°C to +80°C |
| Stroke | 75.9 mm |
| Total Length | 323.0 mm |
| Port thread 11 | 3/8" - 18 NPTF |
| Port thread 12 | 3/8" - 18 NPTF |
| Bolt Threads | 5/8'' - 11 UNC |
| Push-Rod Length | 90.2 mm |
| Bolt Lengths | 38.0 mm |
| Clevis Pins | 12.9 mm |
| Distance between bolts | 120.6 mm |
| Type | 30/36 |
| Version | Without boot |
| Release Pressure | 4.9 bar |
| Type Of Operation | Cam |
WABCO 9253940110 Cross Reference
We have 1 alternatives for the 9253940110 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
