(888) 312-8812 Login SignupWABCO 4235061880 Air Brake Chamber - Unistop Series, Disc Brakes
Tap to view 3 more
$10749
14 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4235061880 Part Description
Brake Chamber (Disc Brake)
WABCO 4235061880 Specifications
Product Attributes
| Push-Rod Length | 15 mm |
| Type | 24 |
| Return-Spring Force | 190 N |
| Bolt Lengths | 38.5 mm |
| Type Of Operation | Disc |
| Push-rod thread | Ball R8 |
| Weight | 0.0022046 |
| Distance between bolts | 120.6 mm |
| Stroke | 65.0 mm |
| Max. operating pressure | 10.2 bar |
| Port threads | 3/8" - 18 NPTF |
| Bolt Threads | M16 x 1.5 |
| Temperature Range | -40°C to +80°C |
| Total Length | 121.0 mm |
| Version | Without boot |
WABCO 4235061880 Cross References
We have 3 alternatives for the 4235061880 by WABCO:
WABCO 4235061880 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4235061880 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
