Name: WABCO 4008630010 ABS Modulator Valve - 24 Volt 1 Port
SKU: 4008630010
Price: 574.49 USD
Availability: InStock

WABCO part description

Valve, ABS Mod 24V 1 Port

Product Attributes

Size	222 x 95 x 232
Voltage	24 V
Rated current	1650 mA
Max. operating pressure	13.0 bar
Distance Between Holes	71x20 mm
Electrical connection	Bayonet DIN 72 585 A1-3.1-Sn/K1
Exhaust	Flap
Temperature Range	-40°C to +80°C
Calculated Volume (dm³)	4.893
Mounting	2x Ø 8.5 mm
Weight	0.01
Port thread 1	1/2" - 14 DRYSEAL NPTF
Protection class	IP 6K6K / IP 6K9K
Port thread 2	1/2" - 14 DRYSEAL NPTF

WABCO 4008630010 Cross Reference

We have 3 alternatives for the 4008630010 by WABCO:

Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
